CPU Module: NP1P

„Features
• Ultra-high-speed processing
Regarding the basic instructions, the CPU module carries
out ultra-high-speed processing as below:
SPH3000MG: 6 ns SPH3000/SPH3000MM: 9 ns
SPH300: 20 ns SPH2000: 30 ns SPH200: 70 ns
• Multi CPU configuration (SPH200 excluded)
Up to 8 CPUs can be configured. High-speed control is
performed through load distribution.

• Redundancy (SPH300/SPH2000)
1:1 warm-standby feature and N:1 backup feature improves
the system safety and reliability.
(N:1 backup feature is supported only by SPH300.)
• IEC 61131-3
Complete compliance with the IEC 61131-3 international
standard language This enables results of programming to
be comprehended worldwide.

NP1PS-32 NP1PS-32R NP1PS-74R NP1PS-117R NP1PS-245R NP1PS-74D NP1PM-48R NP1PM-48E NP1PM-256E NP1PM-256H NP1PH-08 NP1PH-16 NP1PU-048E NP1PU-128E NP1PU-256E NP1PU-048EZM NP1PU-096EZM NP1PU-0128EZM NP1PU-256EZM NP1PU2-048E NP1PU2-256E NP1PU1-256NE NP1PU1-512H NP1PUBM-048C NP1PA1-096E NP1PA1-128E NP1PA1-256E NP1PA1-512E NP1PA1C-096E NP1PA1C-128E NP1PA1C-256E NP1PA1C-512E NP1PS-32 NP1PS-32R NP1PS-74R NP1PS-117R NP1PS-245R NP1PS-74D NP1PU-048EZM NP1PU-096EZM NP1PU-256EZM NP1PU-256EZM  NP1PU1-256NE NP1PU1-512H NP1PUBM-048C NP1PA1C-096E NP1PA1C-128E NP1PA1C-256E NP1PA1C-512E
